·SWFM560 Machine is equipped with no paper miss sensor, which are controlled by photoelectric and mechanical systems. When no paper or paper break occurs, the machine will stop automatically for self-protection.
·Man-machine interface system : color touch screen simplifies the machine operation. On the touch screen, working status of the machine can be checked at any time.
·Upper and down heating roller are equipped with special heater for raising temperature. Individual temperature control perfected the temperature keep steady, ensure the precision of double side lamination temperature.
·Pneumatic pressuring system provides automatically stable pressure to guarantee good laminating quality. And the pressure can also be adjusted upon requests.
·Pneumatic separator system realizes automatic paper separation.
·After separation,paper sheets are collected by paper receiving table.
|
Model |
SWFM-560C |
|
Max paper size |
560mmx800mm |
|
Mini paper size |
150x200mm |
|
Paper thickness |
100~500gsm |
|
Operating speed |
0-20m/min |
|
Laminatingtemperature |
85~90℃ |
|
Total power |
10kw |
|
Dimensions(LxWxH ) |
2.7x1.44x1.4m |
|
Pressure mode |
Automatic |
|
Feeding mode |
by hands |
|
Slitting funtion |
with |
|
Anti-curl function |
with |
|
Auto pull of film after laminating |
Yes |
|
Pressure |
3~10Mpa |
|
Heating mode |
Electromagnetic heating and oil heating |
|
no paper miss sensor |
with |
|
Voltage |
380V/50Hz |
