Senwei Automatic Digital Creasing Machine 371 Y
Creasing blade heat treatment width 0.05 (more beautiful Creasing)
Rice noodle knife imported from Japan (strong penetration)
Maximum feed size 335-655 (extendable)
Minimum feed size 210-297
Creasing paper thickness 128-350 g
Dotted line thickness 128-250 g
Max number of creasing tracks 32
Creasing/dptted line depth infinitely adjustable
Maximum height of paper 110 mm
Operating speed 3850 sheets/hour
Feeding method: suction
Operation keyboard: Chinese and English LCD display device (optional touch screen)
All machine heat treatment
The main machine parameters
|
Model |
SMFM-371Y |
|
Max paper size |
335x655mm |
|
Mini paper size |
210x140mm |
|
Operating speed |
3850 Sheets/hour |
|
Number of indentation |
32（group） |
|
Total power |
195w |
|
Voltage |
220V/50Hz |
|
Feeding mode |
Suction |
|
Max height of paper |
110mm |
| Thickness of creasing tracks | 100g-350g |
| Thickness of dotted line paper | 128g-200g |
| Dimension | 1.185×0.56×0.409m |
